Needham's Electronics


Adapters for all units

Not original adapters but for reference only

  Model # Package Type Pins Description
PD20-121 PLCC 20 20 pin PLCC to 20 pin DIP adapter
for 16v8, a 1 to 1 DEAD BUG adapter
(can also be used on SA-10/20 and EMP series)
PD20-17x PLCC 20 20 pin PLCC to 8 pin DIP adapter
for Atmel and Xilinx 17x configurator PROMs, DEAD BUG
(can also be used on SA-10/20 and EMP series)
PD22v PLCC 28 28 pin PLCC to 24 pin DIP adapter
for 22V10 and 20V8
(can also be used on SA-10/20 and EMP series)
PD28 PLCC 32 32 pin PLCC to 28 pin DIP adapter
for 2764-512, 27011, 87C256, 2864-256 + others
(can also be used on SA-10/20 and EMP series)
PD32 PLCC 32 32 pin PLCC to 32 pin DIP adapter
for EPROMs 27010,100,101,301,1001,020,201,
2001,040,401,4001. also supports 28F256-020
can also be used on SA-10/20 and EMP series)
PD44 PLCC 44 44 pin PLCC to 40 pin DIP adapter
for 16 EPROMs 27210,102,1024,220,202,2048
240,4002, and 4096.
also supports 8748/49, and 8751 families.
(can also be used on SA-10/20 and EMP series)
PD16x-44 PLCC 44 44 pin PLCC to 40 pin DIP adapter
for MICROCHIP (PIC)
16C64, 16C65, 16C67, 16C642, 16C662, 16C74,
16C77, 16F874, 16F877, 18C442, 18C452
(can also be used on SA-10/20 and EMP series)
SO150-16p SOIC 16 16 pin SOIC to 16 pin DIP adapter
for Pic16C505, Pic12Cx and most serial EEPROMs

1 to 1 adapter for 150, 152, 153 mil SOIC
(can also be used on SA-10/20 and EMP series)

SO200-20p SOIC 20 20 pin SOIC to 20 pin DIP adapter
for Pic12C5x, ATTinys and most serial EEPROMs

1 to 1 adapter for 200, 208 mil SOIC
(can also be used on SA-10/20 and EMP series)

SO300-28p SOIC 28 28 pin SOIC to 28 pin DIP adapter
for PLDs 16V8, 20V8, 22v10 most Pic, AVR over 8 pins,

1 to 1 adapter for 300 mil SOIC
(can also be used on SA-10/20 and EMP series)

SS53-121-20p SSOP 20 20 pin SSOP to 20 pin DIP adapter
most common use Atmel 20 pin AVRs,

1 to 1 adapter 5.3 mm SSOP
(can also be used on SA-10/20 and EMP series)

SS53-16x-20p SSOP 20 20 pin SSOP to 18 pin DIP adapter
most common use SSOP Pic micros,

1 to 1 adapter 5.3 mm SSOP
(can also be used on SA-10/20 and EMP series)

TQ44-16x TQFP 44 44 pin TQFP to 40 pin DIP adapter
for MICROCHIP (PIC)
16C64, 16C65, 16C67, 16C642, 16C662, 16C74,
16C77, 16F874, 16F877, 18C442, 18C452
(can also be used on SA-10/20 and EMP series)
TQ44-51 TQFP 44 44 pin TQFP to 40 pin DIP adapter
supports many 87c5x,
89c5x, 78E5x, 90S8515/90S4414
micro-controllers in the 12MM
tip-to tip TQFP package
(can also be used on SA-10/20 and EMP series)
TS32 TSOP 32 32 pin TSOP to 32 pin DIP adapter
for EPROMs 27010,100,101,301,1001,020,201,
2001,040,401,4001. also supports 28F256-020
(can also be used on SA-10/20 and EMP series)
TSS44-20-121 TSSOP 20 20 pin TSSOP(4.4MM) to 20 pin DIP adapter
Wired one-to-one
Supports most serial EEPROMs, 16v8 EPLDs
(can also be used on SA-10/20 and EMP series)
TSS44-520 TSSOP 20 20 pin TSSOP(4.4MM) to 20 pin DIP adapter
Designed to support the
Atmel/Winbond 27C/LV/E520 family of
multiplexed OTP EPROM/FLASH devices
(can also be used on SA-10/20 and EMP series)
Original A52 Needham Adapter
